Bandsaws



The UK’s leading bandsaw blade repair & band saw manufacturer for over five decades

Ernest Bennett have been supplying specialist wood bandsaw blades & industrial bandsaw services for over 50 years and we pride ourselves on the quality and service we give to our customers. We offer sawmill bandsaw blades in a choice of 3 types of steel, all supplied from the Bohler Uddeholm group, renowned as being the best steel for wood bandsaw blades in the world. Uddeholm have been the leaders in wood cutting band saw blades’ strip technology since 1886 and Ernest Bennett is now their largest customer in the UK with purchases of over 60 tonnes of steel per year for our industrial band saw blades. We always choose the highest quality materials to produce our sawmill bandsaw blades- because we believe the highest standards of excellence are at the heart of our company and its traditions.



The UK’s finest woodworking band saw blades, created by our expert team

The benchmark for top quality sawmill bandsaw blades is Uddeholm‘s 148 grade steel, or "UDDEHOLM 000" as it is better known. This is the steel most suitable for industrial horizontal band saw blades, as it is tough enough to allow the teeth to be swaged without cracking and breaking during work, & is also suitable for tipping. Swaging in particular creates very exacting demands on the toughness of wood cutting band saw blades. The steel’s toughness, or ductility are more important than its hardness. The bandsaw steel must also have good resistance to wear if the life of the teeth is to be prolonged. Since resistance to wear is dependent on hardness the steel should be as hard as possible, but not too hard so as to become brittle and unable to withstand swaging. Because wood band saw blades are subject to severe impact stresses while in use the steel must have good impact resistance. The steel must also have good resistance to fatigue as the bandsaw blade must withstand repeated bending and straightening over the bandsaw wheels. The steel must also have good straightness and flatness, combined with good elasticity and resilience. Uddeholm 000 is the best steel for meeting all of these demands.



However, Uddeholm 000 is not the only steel available from the Bohler Uddeholm group. With the development of tipped bandsaw blades some of the characteristics of Uddeholm 000 are not required and we move to "Uddeholm 170". This steel has a higher hardness and tensile strength, which allows it to hold tension longer and cut more accurately. With the stellite tips it allows the saw blade to run for up to 4 times longer on the bandsaw machine giving much better productivity in a high precision, high speed mill. With the higher hardness however this grade of steel is not suitable for swaged industrial bandsaw blades.



The third Bohler Uddeholm steel we supply is Martin Miller steel. This is a high-performance alternative to Uddeholm 000, but at a slightly lower price. Martin Miller joined the Bohler Uddeholm group in 1997, but was founded in 1782 and started producing saw steel in 1869. It does not have the well known name of Uddeholm but is part of the same group and produces excellent quality steel.



Industrial band saw manufacturers with history & a reputation for excellence

Ernest Bennett use the latest technology for producing, servicing and sharpening band saw blades. The teeth are pressed out using a CNC controlled press feed and cut-to-length line, ensuring accuracy of pitch and position of the weld. The welded joint is tempered to 460 deg C to prevent cracking on the weld. The saw blades are then tensioned on automatic machinery before a manual inspection of the joint and the back edge. We then use Mig tipping machines to melt the stellite tip on to the teeth which gives a better adhesion to the saw blade to reduce tip failure and reduce the porosity of the stellite. The saw blades are then ground on CNC wet grinding machines before a final inspection and being packaged for dispatch to the customer. Industrial bandsaw operators should be aware that a woodworking bandsaw blade has a tendency to stretch during the first time of use and it is for this reason that it is recommended a new saw blade should be run in on the machine the first time it is used to prevent damage to the bandsaws. Our recommendation is to run the saw blades without cutting for half an hour, then light cutting for 2 hours and then have the saw serviced. It is also recommended to follow the bandsaw machine manufacturer’s maintenance schedule in order to prevent damage to the bandsaws blade. For your information we have listed our recommendations below in our troubleshooting and maintenance guides.







Already using woodworking band saw blades in your business? Check out our bandsaw blade repair & saw blade sharpening services, which help get you get the most out of each blade while ensuring smooth running of business thanks to our comprehensive national collection network.
